FR2124 ESD Clip

ESD Clip – Description

An ESD Clip is a small, electrostatic discharge-safe component used to ground personnel, tools, or equipment in ESD-sensitive environments. It ensures that static electricity is safely discharged to ground, protecting electronic components from potential damage during handling or assembly.

Types of ESD Clips

1. Alligator Clips

   • Commonly used on wrist straps or grounding cords

   • Attach easily to metal surfaces or grounding points

2. Banana Plug Clips

   • Plug into grounding jacks or sockets

   • Often used with grounding cords and mats

3. Crocodile/Metal Spring Clips

   • Used to connect components or surfaces to a common ground

   • Provide a firm, reliable grip

4. PCB ESD Clips

   • Temporarily ground printed circuit boards (PCBs) during inspection or rework

Key Features

• Conductive or dissipative materials: Often made of stainless steel, copper, or nickel-plated metal

• ESD-safe coating or insulation (optional)

• Durable and corrosion-resistant

• Compatible with ESD wrist straps, cords, mats, and other grounding devices

Common Applications

• Grounding wrist straps to ESD-safe workstations

• Connecting mats, carts, or equipment to ground

• Temporary grounding of PCBs or components during repair or assembly

• Use in electronics manufacturing, assembly lines, and service stations

Benefits

• Prevents electrostatic damage to sensitive electronics

• Easy to use and attach

• Supports compliance with ANSI/ESD S20.20 standards

• Provides reliable and consistent grounding
